Buy Sany 2025 SR285R-C10 Rotary Drilling Rig – Latest Model - Ajman

Features
High Performance and Flexibility
Ideal for small-diameter and deep borehole projects, ensuring rapid hoist speeds and precise vertical boreholes with high operational efficiency.
Robust Chassis Design
A telescoping wide chassis combined with a large-diameter roller slewing bearing provides superior stability during deep drilling.
Energy-Saving Engine
The imported EFI engine features power optimization technology that adjusts power dynamically for faster response and fuel savings.

Parameters
Main Chassis
Base Engine: Isuzu 6WG1
Engine Power: 300/1800kW/rpm
Emission Regulation: China Stage III
Rotary Drive
Rated Speed: 5~24rpm
Rated Output Torque: 285kN·m
Pile
Max. Pile Diameter: 2300mm
Max. Pile Depth: 94/61m
Crowd System
Crowd Force: 260kN
Stroke: 6000mm
Line Pull: 335kN
Overall Machine
Overall Height: 25425mm
Operating Weight: 100T
Transport Width: 3490mm
Transport Height: 3690mm
Main Winch
Lifting Capacity: 330kN
Max. Line Speed: 72m/min
Rope Diameter: 36mm

Price: AED 3328000
Request for quote: +971525384269
